New TYM T5074
Description
TYM T5074 — Specifications
Engine
Specification | Details |
Engine Manufacturer | Yanmar |
Engine Model | 4TN98CT-7PKTF |
Engine Type | Liquid-cooled, turbocharged, 4-cylinder diesel |
Engine Horsepower | 71.5 HP |
PTO Horsepower | 60.2 HP |
Displacement | 3.3 L / 202.5 cu. in. |
Rated Engine Speed | 2,400 RPM |
Fuel System | Common rail direct injection |
Fuel Tank Capacity | 19 gallons |
Transmission & Drivetrain
Specification | Details |
Transmission | Power shuttle |
Number of Speeds | 12 forward / 12 reverse |
Maximum Travel Speed | 13.5 MPH |
Drive System | Four-wheel drive |
Steering | Hydrostatic power steering |
Brakes | Wet disc |
Clutch | Wet multi-plate |
Shuttle Control | Adjustable shuttle sensitivity |
PTO & Hydraulics
Specification | Details |
PTO Type | Independent |
PTO Engagement | Electro-hydraulic |
Rear PTO Speeds | 540 / 750 RPM |
Hydraulic Pump | Dual gear pump |
Implement Hydraulic Flow | 10.3 GPM |
Steering Hydraulic Flow | 5.8 GPM |
Total Hydraulic Flow | 16.1 GPM |
Three-Point Hitch | Category II |
Hitch Lift Capacity | 4,329 lbs. |
Lift Capacity at 24" Behind Link Ends | 3,159 lbs. |
Hitch Control | Mechanical position and draft control |
Lower Hitch Links | Telescopic |
Operator Features
Feature | Details |
Operator Station | Open station with ROPS |
Operator Seat | Adjustable sliding seat with backrest and cushion adjustments |
Loader Controls | Standard 2-button joystick |
Connectivity | USB charging port |
Convenience | Cup holder and storage tray |
Telematics | Standard TYM monitoring system |
Dimensions & Weight
Specification | Details |
Overall Length with Three-Point Hitch | 148.1" |
Overall Width | 81.4" |
Height to Top of ROPS | 106.8" |
Wheelbase | 84.6" |
Minimum Ground Clearance | 17.6" |
Tractor Weight with ROPS | 5,463 lbs. |
Standard Agricultural Tires
Position | Tire Size |
Front | 11.2-24 |
Rear | 16.9-30 |
Manufacturer specifications shown for the open-station configuration. Tires, attachments, and installed options may vary by unit.
